Tucson FWD L4-2.0L (2007)
Tightening torque
Tensioner bolt 43 - 55 Nm (430 - 550kgf-cm, 32 - 40 ft. lbs.)
4) Recheck the belt tension. When the tension side of timing belt is pushed horizontally with a moderate force [approximately 2kg (20N, 5 lbs.)
], the timing belt cog end sags in approximately 4 - 6 mm (0.16 - 0.24 inch)
10. Turn the crankshaft two turns in the operating direction (clockwise) and realign crankshaft sprocket and camshaft sprocket timing mark.
11. Install the timing belt lower cover (A) with 5 bolts (B).
Tightening torque
Timing belt cover bolt 8 - 10 Nm (80 - 100 kgf-cm, 6 - 7 ft. lbs.)
