Timing Belt: Service and Repair

WARNING: INCORRECT REMOVAL OR INSTALLATION OF THE TIMING BELT CAN RESULT IN DAMAGE TO INTERNAL
ENGINE COMPONENTS.

TIMING BELT REPLACEMENT

CAUTION:
-

Do not bend or twist timing belt.

-

WARNING:  AFTER REMOVING TIMING BELT, DO NOT TURN CRANKSHAFT AND CAMSHAFT SEPARATELY BECAUSE
VALVES WILL STRIKE PISTON HEADS.

-

Make sure that timing belt, camshaft sprocket, crankshaft sprocket and belt tensioner are clean and free from oil and water.
