Diode: Specifications
- Make
- Isuzu
- Model
- Axiom 4WD
- Engine
- V6-3.5L
- Year
- 2004
- Section
- Diode › Specifications
Power and Ground DistributionSpecifications
Diode: Specifications – diagram from the Power and Ground Distribution chapter of the Isuzu Axiom 4WD V6-3.5L (2004) factory manual.
Diode Specifications And Configurations
Pinch or Ctrl + scroll to zoom. Double-tap to reset.
