Alignment (Front Suspension): Service and Repair

Make

Isuzu

Model

Hombre

Engine

L4-2.2L CPC

Year

1996

Section

Alignment › Service and Repair › Front Suspension

MaintenanceFront Suspension · page 1 of 3

Alignment: Service and Repair
Front Suspension

Fig. 1  Caster angle adjustment

Fig. 2  Camber angle adjustment

Caster angle can be adjusted with caster shims installed in position between the chassis frame and the fulcrum pins, Fig. 1.
Camber angle can be adjusted with the shims installed in position between the chassis frame and the fulcrum pins, Fig. 2.
