Impulse L4-1994cc 2.0L (4ZC1-T) (1989)

  • Maintenance
  • Timing Belt
  • Component Information
  • Specifications

Page 1
background image

Timing Belt: Specifications



Tensioner Bolt

13.7 ft.lb







Timing Belt Cover Bolt

5.8 ft.lb







Crankshaft Pulley Bolt

86.8 ft.lb
