Isuzu Rodeo S 2WD V6-3.2L (1998)06 · Transmission and Drivetrain
06 · Transmission

Flex Plate: Specifications

Make
Isuzu
Model
Rodeo S 2WD
Engine
V6-3.2L
Year
1998
Section
Flex Plate › Specifications
Transmission and DrivetrainSpecifications
background image

Flex Plate: Specifications



Flywheel Bolts

54 Nm (40 ft.lb)

Do not reuse the bolts and do not applt oil or thread lock



to the bolts.









Flywheel: Torque In Sequence To 54 Nm (40 Ft.lb.)
