Optima L4-2.4L (2001)
Drive Belt: Specifications
CHECKING BELT TENSION
Apply 100 N (22 lbs.) force to the backside of the belt between the pulleys as shown in the illustration, measure the amount of deflection Measure
tension with a tension gauge.
Standard value (For 2.4L DOHC ENGINE)
