Sephia Sedan L4-1.6L (1996)
Timing Belt: Service and Repair
Removal
FUNCTIONAL DIAGRAM
1. Timing Belt
2. Cylinder Head Gasket
3. Hydraulic Lash Adjuster (HLA)
4. Front Oil Seal
5. Rear Oil Seal
