Spectra L4-2.0L (2004)
11. Install the timing belt lower cover(A) with 5bolts(B).
Tightening torque: 7.8 - 9.8Nm (0.8 - 1.0 kg-m, 5.8 - 7.2 ft. lbs.)
12. Install the flange and crankshaft pulley(A), and then tighten crankshaft pulley bolt(B). Make sure that the crankshaft sprocket pin fits into the small
hole in the pulley.
Tightening torque: 166.7 - 176.5Nm (17 - 18kg-m, 123.0 - 130.2 ft. lbs.)
13. Remove the power steering pump and use a wire to secure the pump to the vehicle so that it is out of the way.
Tightening torque: 7.8 - 9.8Nm (0.8 - 1.0 kg-m, 5.8 - 7.2 ft. lbs.)
14. Install the water pump pulley and 4 bolts.
15. Install the power steering pump drive belt.
16. Install the air conditioner compressor drive belt.
17. Install the alternator drive belt.
18. Tighten the bolts of water pump pulley.
