Body fittingsSun roof SPOLIER - R.R.
Sun roof SPOLIER - R.R.
Removing
- Move the sun roof as far back as necessary to gain access to the fixing bolts.
1. Undo the fixing bolt (1a), on both sides, and remove the spoiler (1b).
2. Release the spring, complete with support, and remove it.
Refitting
1. Fit the spring, complete with support, in the housing.
2. Position the spoiler (2a) and tighten the fixing bolts (2b).
