Lancia Ypsilon Factory Service Manual (2003-2011)19 · Wiring diagrams and electrical functions
19 · Electrical

HEADLAMP WASHER - Wiring diagram

Make
Lancia
Model
Ypsilon Factory Service Manual
Year
2003–2011
Section
Electrically activated devices › HEADLAMP WASHER - Wiring diagram
Wiring diagrams and electrical functionsHEADLAMP WASHER - Wiring diagram

HEADLAMP WASHER - Wiring diagram

Wiring diagram

HEADLAMP WASHER - Wiring diagram

COMPONENTS

Component codeNameAssembly reference
A1Battery5530B
B1Engine compartment junction unit5505A
B2Junction unit under dashboard5505A
C20Passenger side dashboard earth
C38Earth on tunnel
H1Ignition switch5520A
H5Steering column switch unit5550A
M1Body computer5505A
N25Headlamp washer pump motor
