Colour: YELLOW Gender: Female
- Make
- Land Rover
- Model
- Defender Electrical Library
- Year
- 2002 on
- Section
- C0730 Relay - Fuel pump › Colour: YELLOW Gender: Female
ConnectorsColour: YELLOW Gender: Female
| Cav 30 | Col WP | Cct 4 |
| 85 | UP | 4 |
| 86 | NO | 4 |
| 87 | PW | 4 |
Description: Relay - Fuel pump Location: Beneath RH seat
Colour: YELLOW Gender: Female
