Discovery II
AUTOMATIC GEARBOX - ZF4HP22 - 24
44-48
REPAIRS
Filter - oil
$% 44.24.07
Remove
1. Remove oil sump gasket.
- 24, REPAIRS, Gasket - oil sump.
2. Remove Torx screw securing oil pick-up tube
and remove tube.
3. Remove 2 Torx screws securing filter to valve
body and discard 'O' rings.
Refit
1. Clean filter and pick-up tube using a lint free
cloth.
2. Fit new 'O' rings to filter.
3. Position filter and tighten Torx screws to 8 Nm
(6 lbf.ft).
4. Position oil pick-up tube and tighten Torx
screw to 8 Nm (6 lbf.ft).
5. Fit oil sump gasket.
