Discovery II
ENGINE - V8
REPAIRS 12-2-19
Gasket - rocker cover - LH
$% 12.29.40
Remove
1. Remove upper inlet manifold gasket.
SYSTEMS - V8, REPAIRS, Gasket - inlet
manifold - upper - Without Secondary Air
Injection.
2. Models with air conditioning: Release 4
clips and remove fan cowl.
3. Models with air conditioning: Release
tension on auxiliary drive belt and remove belt
from air conditioning compressor. Disconnect
compressor multiplug. Remove 4 bolts
securing compressor and position compressor
aside.
4. Release ht leads from rocker cover clips.
5. Remove screw securing dip stick tube.
6. Noting fitted position of 2 long screws or multi-
hex bolts, remove and discard screws/bolts
securing rocker cover; remove rocker cover.
CAUTION: Screws/bolts must be replaced
with new 'patched' multi-hex bolts.
7. Remove and discard rocker cover gasket.
