300Tdi Discovery
75
SUPPLEMENTARY RESTRAINT SYSTEM
16
REPAIR
3. Knee bolster (where fitted); Remove 4 screws
and withdraw kneebolster.
4. Release airbag harness to column harness
connector from bracket.
5. Disconnect airbag harness connector from
column harness.
WARNING: Ensure tool is not connected to
battery.
6. Connect flylead SMD 4082/5 to column harness
connector.
7. Connect flylead SMD 4082/5 to tool SMD
4082/1.
WARNING: Ensure airbag module is
secure within steering wheel.
8. Connect tool SMD 4082/1 to battery.
WARNING: Ensure all personnel are
standing at least 15 metres (50 ft) away
from vehicle.
