Freelander Service Procedures
BRAKES
REPAIRS
70-5
Disc - front
$% 70.12.10
Remove
1. Raise front of vehicle.
WARNING: Do not work on or under a
vehicle supported only by a jack. Always
support the vehicle on safety stands.
2. Remove road wheel(s).
3. Remove 2 bolts securing brake calliper to
swivel hub.
4. Release calliper from disc and tie aside.
CAUTION: Do not allow calliper to hang on
brake hose.
5. Remove 2 screws securing brake disc to drive
flange.
6. Remove brake disc from drive flange.
Refit
1. Clean brake disc and drive flange mating faces.
2. Fit disc to drive flange, fit screws and tighten to
5 Nm (3.5 lbf.ft).
3. Clean mating faces of calliper and hub.
4. Position calliper to brake disc fit bolts and
tighten to 100 Nm (74 lbf.ft).
5. Fit road wheel(s) and tighten nuts to 115 Nm
(85 lbf.ft).
6. Remove stand and lower vehicle.
