Freelander Service Procedures
BRAKES
70-6
REPAIRS
Hose - front - primary - LH
$% 70.15.02
Remove
1. Raise front of vehicle.
WARNING: Do not work on or under a
vehicle supported only by a jack. Always
support the vehicle on safety stands.
2. Remove road wheel(s).
3. Loosen brake pipe union to hose and release
union.
CAUTION: Always fit plugs to open
connections to prevent contamination.
4. Remove 2 clips securing hose to valance and
damper bracket.
5. Release clips securing ABS sensor lead to
brake hose.
6. Remove banjo bolt securing brake hose to
calliper and collect sealing washers.
7. Remove brake hose and plug brake calliper.
Refit
1. Remove plugs and clean brake pipe male end.
2. Position hose to support brackets and secure
with clips.
3. Clean banjo bolt, hose and calliper mating
faces.
4. Using new sealing washers, align hose to
calliper, fit banjo bolt and tighten to 28 Nm (21
lbf.ft)
5. Align hose to brake pipe and tighten union to 17
Nm (12 lbf.ft).
6. Secure ABS sensor lead to brake hose.
7. Bleed brakes.
8. Fit road wheel(s) and tighten nuts to 115 Nm
(85 lbf.ft).
9. Remove stand(s) and lower vehicle.
