Freelander Service Procedures
DOORS
76-1-12 REPAIRS
Glass regulator - tail door
$% 76.31.65
Remove
1. Remove rear screen.
DOORS, REPAIRS, Glass - tail door.
2. Disconnect multiplug from regulator motor.
3. Loosen 3 nuts securing regulator motor and
rotate motor to release from door.
4. Loosen 4 nuts securing top of cable guides and
release guides from door.
5. Remove 2 nuts securing pre-load adjusters and
rotate adjusters fully clockwise to improve
access.
6. Release regulator from door and detach
electrical harness from LH glass clamp.
7. Remove regulator from door.
Refit
1. Position regulator to door and unclip motor
transit package from rail.
2. Connect multiplug to regulator motor.
3. Connect harness clip and align regulator to
door.
4. Fit nuts to pre-load adjusters, but do not tighten
at this stage.
5. Position tops of cable guides to door, leaving
fixings finger tight.
6. Tighten regulator motor fixings.
7. Fit rear screen.
