Trim casing - tail door
- Make
- Land Rover
- Model
- Freelander Service Procedures
- Section
- REPAIRS › Trim casing - tail door
DOORSTrim casing - tail door
DOORS
76-1-22 REPAIRS
Trim casing - tail door
$% 76.34.10
Remove
1. Remove 4 screws securing bottom of trim
casing to door.
2. Release 8 clips securing sides and bottom of
casing.
3. Release 5 clips securing top of casing and
remove casing.
4. Remove 8 trim studs from casing.
Refit
1. Fit trim studs to casing.
2. Position casing and secure top clips.
3. Secure clips on sides and bottom of casing.
4. Fit screws to bottom of casing.
