Freelander Service Procedures
ENGINE MANAGEMENT SYSTEM - SIEMENS
REPAIRS
18-3-7
Idle Air Control Valve (IACV)
$% 18.30.05
Remove
1. Disconnect battery earth lead.
2. Remove engine acoustic cover.
ENGINE - K SERIES KV6, REPAIRS,
3. Disconnect multiplug from IACV.
4. Depress locking collar and release vacuum
hose from IACV housing.
5. Remove 2 Allen bolts securing IACV to throttle
body.
6. Remove IACV and discard gasket.
Refit
1. Clean mating faces of IACV and throttle body.
2. Fit new gasket to IACV.
3. Position IACV to throttle body, fit and tighten
Allen bolts.
4. Connect vacuum hose to IACV.
5. Connect multiplug to IACV.
6. Fit engine acoustic cover.
ENGINE - K SERIES KV6, REPAIRS,
7. Connect battery earth lead.
