Freelander Service Procedures
ENGINE MANAGEMENT SYSTEM - SIEMENS
REPAIRS 18-3-13
Sensor - knock (KS)
$% 18.30.28
Remove
1. Disconnect battery earth lead.
2. Remove LH inlet manifold.
- K SERIES KV6, REPAIRS, Gasket - inlet
manifold - LH.
3. Disconnect KS multiplug.
4. Note the routing of each KS harness.
5. Remove 2 bolts securing KS to cylinder block
and remove sensors.
Refit
1. Clean KS and mating faces on cylinder block.
2. Position KS, ensure that harnesses are
correctly routed, fit and tighten bolts to 25 Nm
(18 lbf.ft).
3. Connect KS multiplug.
4. Fit LH inlet manifold.
- K SERIES KV6, REPAIRS, Gasket - inlet
manifold - LH.
5. Connect battery earth lead.
Switch - throttle pedal - Non NAS
$% 18.30.36
Remove
1. Remove 2 nuts securing throttle pedal
assembly to bulkhead.
2. Release clip securing throttle inner cable to
throttle pedal and disconnect inner cable from
pedal.
3. Disconnect multiplug from throttle pedal switch.
4. Remove throttle pedal assembly from vehicle.
