L322 Range Rover Service Procedures
ENGINE - V8
REPAIRS 12-2-35
30. Remove 2 nuts securing engine harness to
induction manifold, remove washer and release
SAI control valve from securing stud. Position
valve aside.
31. Disconnect multiplug from RH KS.
32. Disconnect multiplugs from RH fuel injectors
33. Disconnect multiplug from charcoal canister
purge control valve.
34. Position engine harness to RH bulkhead.
35. Disconnect pipe from charcoal canister purge
control valve.
CAUTION: Always fit plugs to open
connections to prevent contamination.
M86 5698
M18 0741
