L322 Range Rover Service Procedures
ENGINE - V8
12-2-34 REPAIRS
24. Disconnect multiplugs from LH CMP sensor
and LH knock sensor.
25. Remove 2 nuts securing LH fuel injector
harness to fuel rail, release vacuum reservoir
and mounting bracket from stud and position
aside.
26. Release alternator harness from 2 clips on
engine cover mounting brackets.
27. Disconnect multiplugs from LH fuel injectors
28. Release engine harness from clips and move
clear of camshaft cover.
29. Disconnect multiplug from SAI control valve.
M86 5696
M12 7676
M12 7680
M86 5701
