Description: ECU-Engine Immobilisation
- Make
- Land Rover
- Model
- Range Rover L322 Range Rover Electrical Library
- Section
- C0059 ECU-Engine Immobilisation › Description: ECU-Engine Immobilisation
ConnectorsDescription: ECU-Engine Immobilisation
| Cav 1 | Col B | Cct ALL |
| 2 | BY | 1 |
| 2 | R | 2 |
| 4 | BP | ALL |
| 5 | YU | ALL |
| 6 | BU | 1 |
| 9 | NB | ALL |
| 10 | RY | ALL |
| 11 | PB | ALL |
| 12 | YN | ALL |
| 13 | WRY | ALL |
Description: ECU-Engine Immobilisation
Location: Beneath centre console
Colour: BLACK Gender: Female
