Description: DCU-Airbag

Make

Land Rover

Model

Range Rover L322 Range Rover Electrical Library

Section

C0256 DCU-Airbag › Description: DCU-Airbag

ConnectorsDescription: DCU-Airbag

Cav 1	Col YR	Cct ALL
2	YN	ALL
3	UR	ALL
4	UN	ALL
5	PU	ALL
6	NB	ALL
7	NP	ALL
8	UP	27
9	WRY	ALL
10	YB	ALL
11	YN	ALL
12	UW	16
13	UB	ALL
14	UN	ALL
15	WR	ALL
16	Y	ALL
17	N	ALL
18	U	ALL
19	N	ALL
20	YG	ALL
21	YR	ALL
26	SB	ALL
27	SN	ALL
28	Y	20
29	B	20
33	WB	ALL
34	SU	ALL
40	WN	ALL
41	G	20
42	B	20
45	Y	ALL
46	UY	ALL
47	W	ALL
48	UW	ALL
49	N	ALL
50	NR	ALL

Description: DCU-Airbag

Location: Beneath centre console

Colour: NATURAL Gender: Female

05 General
