Engine Front Cover|Page 999 > < Engine Front Cover|Page 997

LR3/Disco 3

Page 4
background image







16 .

  Disconnect the battery positive cable.



Release the cover.



Remove the nut.



Disconnect the electrical connector.

17 .

  Remove the generator.



Remove the 3 bolts.

18 .

  Remove the generator mounting bracket.



Remove the 4 bolts.

Engine Front Cover|Page 999 > < Engine Front Cover|Page 997
