LR3/Disco 3
Tighten the bolts to 10 Nm (7 lb.ft).
4 .
Using the special tool, install a new torque converter oil seal.
Clean the seal register.
5 .
CAUTION: Make sure the torque converter is fully located into the oil pump drive.
Install the torque converter.
Clean the seal contact area.
Remove the special tools.
6 .
Install the torque converter retainer.
7 .
WARNING: Secure the transmission to the transmission jack.
Position the transmission to the transmission jack.
8 .
Remove the torque converter retainer.
9 .
CAUTION: Apply grease of the correct specification to the torque converter spigot.
With assistance, install the transmission.
Clean the component mating faces.
Tighten the bolts to 45 Nm (33 lb.ft).
10 .
Attach the flexplate to the torque converter.
Rotate the crankshaft to access the bolts.
Tighten the bolts to 45 Nm (33 lb.ft).
11 .
Attach the transmission breather pipe clip.
Tighten the bolt to 25 Nm (18 lb.ft).
12 .
Attach the wiring harness.
