LT230Q Transfer Box
TRANSFER BOX
OVERHAUL
19
Mainshaft input gear
1. Check gear teeth for cracks, chipping and
uneven wear.
2. Check that cross drillings in shaft are clear.
Defender only
3. Check that ends of dog teeth are not
’rounded-off’ or chipped.
High/low cross shaft and housing
1. Check mating surfaces of cross shaft and
drilling in housing for wear.
2. Check core plug in housing for signs of
leakage or corrosion, apply Loctite 326 to
replacement plug.
3. Check high/low selector finger for wear.
4. Measure across widest portion of finger:
Finger width = 15.90 to 15.95 mm (0.625 to
0.627 in)
