INFORMATION
2
TORQUE WRENCH SETTINGS
Timing cover/coolant pump to cylinder
block bolts + **
22 Nm
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16 lbf.ft
Oil pick-up pipe to oil pump bolts
10 Nm
. . . . . . . . . . . . . . . .
8 lbf.ft
Oil pick-up pipe nut
22 Nm
. . . . . . . . . . . . . . . . . . . . . . . . . .
16 lbf.ft
Knock sensors to cylinder block
16 Nm
. . . . . . . . . . . . . . . .
12 lbf.ft
Camshaft sensor to timing cover bolt
8 Nm
. . . . . . . . . . . .
6 lbf.ft
Crankshaft position sensor bolts
6 Nm
. . . . . . . . . . . . . . . .
4 lbf.ft
Oil cooler connections
15 Nm
. . . . . . . . . . . . . . . . . . . . . . . .
11 lbf.ft
Secondary air adapters - If fitted ****
33 Nm
. . . . . . . . . . . . .
24 lbf.ft
+ Tighten in sequence
* Lightly oil threads prior to assembly.
** Coat threads with sealant, Part number STC
50552 prior to assembly.
*** New bolts must be fitted
**** New adapters must be fitted
