Brake Bleeding: Service and Repair – Lexus ES 350 V6-3.5L (2GR-FE) (2007)

Brake Bleeding: Service and Repair

BRAKE FLUID

BLEEDING

HINT:  If any work is performed on the brake system or if air in the brake lines is suspected, bleed the air from the brake system.

NOTICE:
^

Move the shift lever to the P position and apply the parking brake before bleeding the brakes.

^

Add brake fluid to keep the level between the MIN and MAX lines of the reservoir while bleeding the brakes.

^

If brake fluid leaks onto any painted surface, wash off and remove it completely.

1. FILL RESERVOIR WITH BRAKE FLUID

(a)

Fill the reservoir with brake fluid.
Fluid: SAE J1703 or FMVSS No. 116 DOT3

2. BLEED MASTER CYLINDER

HINT:
^

If the master cylinder is reinstalled or if the reservoir becomes empty, bleed the air from the master cylinder.

^

To avoid brake fluid from adhering, cover the painted surface with a shop rag or piece of cloth.

(a)

Using SST, disconnect the 2 brake lines from the master cylinder.
SST 09023-00101
