LS 460 V8-4.6L (1UR-FSE) (2007)
/Page-1501010.png)
(e)
Inspect the front No. 2 suspension upper arm.
(1) Remove the front No. 2 suspension upper arm.
(2) Measure the dimension between the center of the front No. 2 suspension upper arm bush and the ball joint stud.
Standard length: 224.5 mm (8.839 in.)
HINT: If the dimension of the front suspension upper arm changes 2 mm (0.079 in.), the camber will change approximately 15' (0.25°
).
