LS 600h V8-5.0L (2UR-FSE) Hybrid (2008)
_hybrid/Page-973002.png)
(a) Remove the radiator hose.
21. REMOVE NO. 2 RADIATOR HOSE
(a) Remove the radiator hose.
22. DISCONNECT INLET OIL COOLER HOSE
23. DISCONNECT OUTLET OIL COOLER HOSE
24. REMOVE OUTLET ENGINE ROOM ECU DUCT See: Engine/Service and Repair/Removal and Replacement/Engine Assembly/Removal
25. REMOVE WIRE HARNESS
(a) Disconnect the 2 connectors.
(b) Detach the 5 clamps and disconnect the wire harness.
(c) Detach the 3 clamps and disconnect the ECU connector.
26. REMOVE MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System)
