Alignment: Specifications (page 4 of 6)

Make

Lexus

Model

LX 470

Engine

V8-4.7L (2UZ-FE)

Year

1999

Section

Alignment

MaintenanceSpecifications · page 4 of 6

c. How to read adjustment chart (using examples).

1. Measure the present alignment.

Camber: -0°20'(-0.33°)
Caster: 3°15' (3.25°)

2. Mark the difference between the standard value (A) and the measured value (B) on the adjustment chart.

Standard value:
Camber: 0°00' (0°)
Caster: 3°05' (3.08°)
Formula: A - B = C
Camber: 0°00'- (-0°20') = 0°20'
Caster: 3°05'- 3°15' = -0°10'
