3 L4-2.0L (2007)

Page 1
background image

Alternator: Specifications

Alternator

Minimum current value :

70 % of the nominal output current (nominal output current: 90 A)
[Ambient temp. 20 °C (68 °F), voltage 13.0 - 15.0 V, both engine and generator are hot]
