Suspension Technical Data (Alignment) (page 6 of 7)

Make

Mazda

Model

3

Engine

L4-2.5L

Year

2010

Section

Alignment › Specifications

MaintenanceSuspension Technical Data · page 6 of 7

*1

Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.

*2

Difference between left and right must not exceed 1°30'.

Rear wheel alignment (Unloaded)*1 [L3 WITH TC]

*1

Engine coolant and engine oil are at specified level. Spare tire, jack and tools are in designated position.

*2

Difference between left and right must not exceed 1°30'.
