Page 9

background image

Terminal Voltage Table (Reference) Part 1

Relays and Modules
Relays and Modules - Powertrain Management / Relays and Modules - Computers and Control Systems
Engine Control Module / Component Information
Testing and Inspection / Component Tests and General Diagnostics
Page 329
