6 V6-3.0L DOHC (2003)
Flywheel: Specifications
FLYWHEEL
RUN OUT
G35M-R manual transaxle models
Max. ................................................................................................................................................................................................ 0.1 mm (0.004in.)
A65M-R manual transaxle models
Max. ........................................................................................................................................................................................... 0.05 mm (0.002 inch)
TORQUE SPECIFICATIONS
Gradually tighten the flywheel lock bolts in a crisscross pattern.
G35M-R manual transaxle models
Tightening torque ..................................................................................................................... 108 - 115 Nm (11.1 - 11.7 kgf-m, 79.7 - 84.8 ft. lbs.)
A65M-R manual transaxle models
Tightening Torque .................................................................................................................................. 73 - 87 Nm (7.5 - 8.8 kgf-m, 54 - 64 ft. lbs.)
