CX-9 AWD V6-3.7L (2008)
Heater Hose: Service and Repair
HEATER PIPE AND HOSE COMPONENT REMOVAL/INSTALLATION
1. Remove the battery.
2. Drain the engine coolant.
3. Remove the following parts:
1. Windshield wiper arm and blade.
2. Cowl grille.
3. Windshield wiper motor.
4. Cowl panel.
4. Remove in the order indicated in the table.
5. Jack up the vehicle.
6. Under guard (LH).
