Drive Belt: Specifications
A/C Belt Tension and Deflection

A/C Belt Tension and Deflection

Deflection This Vehicle Is Equipped With An Automatic Belt Tensioner, No Adjustment Necessary.







Tension

This Vehicle Is Equipped With An Automatic Belt Tensioner, No Adjustment Necessary.
