MPV LX 4WD V6-3.0L SOHC (1997)

  • Maintenance
  • Drive Belt
  • Component Information
  • Specifications

Page 1
background image

Drive Belt: Specifications

Drive Belt Deflection Specification Chart

Drive Belt Tension Specification Chart
