Wheel Fastener: Specifications

Wheel Fastener

Tighten the wheel nuts in a crisscross pattern to the following.
Tightening torque
 .................................................................................................................................................................  88 - 118 Nm (9.0 - 12.0 kgf-m, 65.0 - 87.0 ft-lbf)
