MX-6 L4-2184cc 2.2L SOHC Turbo F2 (1989)
Drive Belt: Specifications
Drive Belt Deflection
Drive Belt Deflection
Alternator Belt
New
0.24 To 0.31 in
Used
0.27 To 0.35 in
A/C Compressor Belt
New
0.27 To 0.36 in
Used
0.31 to 0.39 in
Power Steering Pump Belt
New
0.31 To 0.39 in
Used
0.35 to 0.43 in
Fig. 13 Belt Routing
