MX-6 LS V6-2.5L DOHC (1997)

Page 2
background image

Engine and transaxle assembly

1. Suspend the engine and transaxle assembly.

Caution:  Do not damage any components in the engine compartment. Lift the engine and transaxle assembly out as a unit.
Disassemble in the sequence shown.

1. Starter
2. Engine mount No.2 rubber
