Eclipse V6-3.8L (6G75) (2006)

Page 1
background image

Brake Rotor/Disc: Testing and Inspection
Disc Brake Rotor Check

DISC BRAKE ROTOR CHECK

CAUTION:  Disc brakes must be kept within the allowable service values in order to maintain normal brake operation.

Before turning the brake disc, the following conditions should be checked.
