Eclipse V6-3.8L (6G75) (2006)
/Page-1256001.png)
Rear Cross-Member: Service and Repair
REAR SUSPENSION CROSSMEMBER
REMOVAL AND INSTALLATION
CAUTION:
For vehicles with ABS, be careful when handling the pole piece at the tip of the wheel speed sensor so as not to damage it by striking against other
parts.
Pre-Removal & Post-installation Operation
Removal Steps 1-7
REMOVAL SERVICE POINTS
<<A>> UPPER ARM ASSEMBLY REMOVAL
