Galant L4-1997cc 2.0L SOHC 16 Valve (1993)
Ignition Monitoring Shunt: Description and Operation
Park/Neutral Position Switch Circuit
AUTOMATIC TRANSMISSION
Ignition Switch (M/T) Circuit
MANUAL TRANSMISSION
OPERATION
The ignition switch supplies "On" and "Start" information to the ECU which then positions the idle speed control components.
-
The ignition switch "ON" signal is provided to the ECU through the control relay.
-
Refer to the images for the "START" signal.
