Galant AWD L4-1997cc 2.0L DOHC (1990)
Drive Belt: Specifications
A/C BELT
Deflection At 22 Lbs.:
New, Inches ............................................................................................................................................................................................ 0.22-0.24
Used, Inches ............................................................................................................................................................................................ 0.26-0.30
ALTERNATOR BELT
Deflection At 22 Lbs.:
New, Inches ............................................................................................................................................................................................ 0.30-0.35
Used, Inches .................................................................................................................................................................................................... 0.39
POWER STEERING BELT
Deflection At 22 Lbs.:
New, Inches ............................................................................................................................................................................................ 0.18-0.22
Used, Inches ............................................................................................................................................................................................ 0.24-0.28
