Lancer L4-2.4L SOHC (2005)
1. Check the pad cover for dents, cracks or deformation.
2. Check the connector for damage, terminals deformities, and the harness for binding.
3. Check the air bag inflator case for dents, cracks or deformities.
4. Install the air bag module (driver's side) to the steering wheel to check fit or alignment with the steering wheel.
5. Install the air bag module (front passenger's side) to the instrument panel and front deck crossmember to check fit or alignment.
FRONT SEATBACK ASSEMBLY (SIDE-AIRBAG MODULE)
1. Check that there is no abnormality in the seat air bag module deployment section.
2. Check that there is no connector damage, bent terminals or clamping of the harness.
CLOCK SPRING
1. Check the clock spring connectors and protective tube for damage, and the terminals for deformation.
2. Visually check the case for damage.
