background image

Timing Belt: Specifications
Engine Mechanical



Timing belt lower cover attaching bolt

10 +/- 2 Nm







Timing belt front upper cover attaching bolt

10 +/- 2 Nm









Timing belt B tension Standard value

5 - 7 mm
