Montero V6-3.8L SOHC (2005)
4. Use special tool MD998767 to push the tensioner pulley into the timing belt, and then temporarily tighten the center bolt.
5. Use special tool MD998769 to turn the crankshaft 1/4 turn counterclockwise and then turn it again clockwise until the timing marks are
aligned.
6. Loosen the center bolt of the tensioner pulley. Use special tool MD998767 and a torque wrench to apply the standard torque to the timing belt
as shown in the illustration. Then tighten the center bolt to the specified torque.
^
Standard value: 4.4 Nm (39 inch lbs.) <Timing belt tension torque>
^
Tightening torque: 48 ± 6 Nm (36 ± 4 ft. lbs.)
7. Remove the setting pin that has been inserted into the auto-tensioner.
8. Turn the crankshaft two turns clockwise to align the timing marks.
